Operation: C1S Version
4-8 CENTRON Meter Technical Reference Guide
Factory Programming Options
Display Timing
The display will scroll between the billing register and the segment check mode
based on the factory programming option.
Digits and Multipliers
The following digit and multiplier settings are available for factory programming:
• 4 digits x 1 kWh
• 4 digits x 10 kWh
• 5 digits x 1 kWh
Although the DEL and REC indicators are ON during segment check, they are not currently used.
Option Description
1 7 second billing register display, 1 second blank, 7 second segment check display (7/7)
2 7 second billing register display, 1 second blank, 1 second segment check display (7/1)
3 Only the billing register is displayed (7/0)
