ITRON EM512 TYPE 700 JV1 User Manual

25
Technical Specifications
Meter Type
Prepaymnet Single Phase meter
Standard
- IEC 62055-31: 2005-09, Electricity metering – Payment sistems – Part 31: Particular
requirements – Static payment meters for active energy (classes 1 and 2)
- IEC 62055-41: 2007-05, Electricity metering – Payment sistem – Part 41: Standard
transfer specification (STS) – Application layer protocol for one-way token carrier
sistems
- IEC 62055-51: 2007-05, Electricity metering – Payment sistem – Part 51: Standard
transfer specification (STS) – Physical layer protocol for one-way numeric and
magnetic card token carriers.
- IEC 62052-11: 2003, Electricity metering equipment (AC) – General requirements,
tests and test conditions, Part 11: Metering equipment
- IEC 62053-21: 2003, Electricity metering equipment – Part 21: Static meter for
active energy (classes 1 and 2)
Network
Single Phase 2 wires
Measuring
Scope
Active Energy
Class Index
Class 1
Reference
voltage &
frequency
120V 60Hz / 220V, 230V, 240V 50Hz/60Hz
Operating
Voltage
Range
-30%Un to +15%Un
Power
Consumption
<2W and <10VA
Basic
Current
5A
Maximum
current
60A/80A
Starting
Current
0.2% Ib
Operating
Temperature
range
-25°C to +55°C
Limit
temperature
Range
to transport
and storage
-25°C to + 85°C
Degree of
Protection
IP 54
Immunity to
impulse
voltage
6kV
Relative
Humidity
Up to 95%
Meter
Weight
1.3 kg
Meter
constant
1000 pulse/kWh
User
Interface
12 digits keypad with audio feedback
7 segment LCD with special symbols
LED Indicator
Optical probe
Infra-Red

ITRON EM512 TYPE 700 JV1 Specifications

General

Brand	ITRON
Model	EM512 TYPE 700 JV1
Category	Measuring Instruments
Language	English
