ITRON OpenWay Riva 500W ERT - Page 19

Pit module wire color
Red (data) Black (power/clock) White (ground)
Register manufacturer Register screw terminal
Diehl Hydrus Green Red Black
Elster AMCO
InVision
Scancoder
AquaMaster
AquaMaster III
Red Green Black
Elster AMCO
SM 700 (Severn Trent)
Q200 (Sensus Protocol)
evoQ4 (Sensus Protocol)
Green Red Black
Elster AMCO evoQ4 Mag Red White Black
Itron (Actaris) Cyble Coder Green Red Black
Kamstrup flowIQ2100 Green Red Black
MasterMeter
AccuLinx
Octave
Green Red Black
McCrometer Data port/green Clock/red Gnd port/black
Metron Farnier OER Green Red Black
Mueller (Hersey)
Translator
SSR
Green Red Black
Sensus
ECR
ICE
iPERL
SRII
OMNI
Green Red Black
Neptune
ProRead
ProRead AutoDetect
E-Coder
ARB-V
Red Black Green
