Pit module wire color
Red (data) Black (power/clock) White (ground)
Register manufacturer Register screw terminal
Performance ETR Green Red Black
RG3 Tomahawk Green Red Black
Siemens
Mag Meter
Mag8000CT-7ME6820
Mag8000-7ME6810
92 91 93
Zenner (Hendey) ETR Green Red Black
Pulser-type Register Connections
Pit module connections are made by the meter manufacturer for pulser-type registers. This
information describes those connections.
Caution: Itron recommends OpenWay Riva pit module connections be completed
using the inline connector. In rare instances, if a spliced connection is made, the Itron
splice kit must be used (Itron part number OEM-0034-002). For more information, see
Completing Gel-cap Connections Using the Itron Splice Kit
Module wire color
Red Black White
Register manufacturer Register screw color designator
Badger RTR (3-wire) Red Black Green
Badger RTR (2-wire) Red Black No connection
Badger M5000 Mag Meter Red terminal: Out 1+ Black terminal: Out 1- White terminal: Out 1+
Cadillac Meter CMAG/EMAG
Magnetic Flow
DO1/DO2 COM DO1/DO2
Elster Digital Black Green Red
Elster V100T Black Red Blue
■
Itron (Actaris)
■
Flostar (2-wire)
Either wire Remaining wire must be connected to both ERT
module wires
08 January 2020 815-0006-01 Itron, Inc. Page 20 of 48
