Safety Instructions and EU Declaration of Conformity:
• This „Instruction manual“ has to be kept on the place, which can be easy reached.
• The regulator has to be used only for dry and clean gases. Never use with oxygen: risk of explosion.
• The national norms and standards about installation, start-up and maintenance of the devices and gas
installations have to be strictly respected.
• The handling with the device has to be done carefully, specially by the installation works. The pick up
has to be made by using the stretcher eyes or belts.
• The device should be examined before the installation for possible transport damages and be mount-
ed only if it is in perfect state. Possible lacquer damage should be improved. The sealing surfaces of
the threaded connections or flanges must be damage-free and clean.
• For reading off the device and its serving are sufficiently space to designate.
• For the protection of the device is recommendable to install a filter.
• The device is to be installed in such a way that it is not impaired in its function by other installation
components.
• The regulator has to be mounted in the pipe line without any tension.
• The mentioned below torque‘s values for screws (property class 5.6) must be respected by tighten of
the flanged connections:
• These torque‘s values are mentioned per screw and are valid for metal soft material gaskets
(specified as k0xKD=45bD und k1=2,2bD). Other gaskets can require another torque‘s values.
• The screws used for the flange connection must be according to the flange size and must be adapted
to the temperature range of the regulator. Please tighten the screws crosswise.
• After the installation works are completed, the tightness of the connections (threaded or flanged)
must be checked with appropriate means.
• The operating conditions indicated on the name plates must be respected; if necessary appropriate
safety devices have to be designated.
• Repairs of the device are allowed to be made only by trained or qualified personal. Afterwards a tight-
ness test with 1.1 X PS must be performed. When changing pressure containing parts their compli-
ance with PED must be assured. After guarantee only with repair by Itron.
• The device has to be regularly examined for corrosion danger in the interior and external area and be
taken from use if noticeable corrosion is discovered.
• The inner chamber volume of the RR 16 regulator amounts to::
• The cleaning of the devices has to be done without using any alcohol containing solvent or cleaning
agents.
• The device is not appropriate for floods and loads by earthquakes.
• The pressure has to be completely discharged before to take the device from the pipe line. The rest
of gas can withdraw; therefore the required ventilation has to be insured.
• The appropriate measures for noise reduction have to be seized depending on the installation place
and work conditions.
DN 25 DN 50 DN 80
PN 16
35Nm
(M12)
85Nm
(M16)
85Nm
(M16)
ANSI 150
40Nm
(
1
/
2
-13 UNC)
85Nm
(
5
/
8
-11UNC)
85Nm
(
5
/
8
-11UNC)
Size 25 50 80
Type 8N 8H 12N 8N 8H 12N 8N 8H
V in litres 6,4 7,4 10,6 7 8 13,6 10 11
