ITT RED JACKET RSPA Series User Manual

5
Electrical Data – All Models
HP Voltage Full Load Amps Circuit Breaker Ph/Hz
3
⁄4 115/230 25/15 1/60
1 115/230 25/15 1/60
1
1
⁄2 115/230 See Motor Nameplate 35/20 1/60
2 230 25 1/60
3 230 30 1/60
Repair Parts List – RJSP
1
5
3
2
10
9
8
7
6
14
13
1
12
11
RJSP Motor Codes
HP 1Ø – ODP
.75 J05853LA
1.0 J06853LA
1.5 J07858LA
2.0 J08854LA
3.0 J09853A
4
Item Description Material 75 100 150 200 300
No. RJSP RJSP RJSP RJSP RJSP
1
1
⁄4" NPT Pipe Plug Plated Steel 6K2
2 Casing Cast Iron 1K449
3 Guidevane Seal Ring BUNA 5K231
4Diaphragm Neoprene 5K256
Fillister Head
Machine Screw
6 Guidevane Lexan
®
10% G.F. 3K72 3K71 3K70 3K70 3K69
7 Impeller Noryl
®
20% G.F. 2K715 2K716 2K714 2K713 2K712
Carbon/Ceramic/
BUNA
9 Pump Foot Steel 4K529
10 Pump Foot Bolt Steel 13K252
11 Motor Adapter Cast Iron 1K450
12 Casing Bolt Steel 13K102
13 Motor Adapter Bolt Steel 13K89
14 Deflector BUNA 5K7
8 Mechanical Seal 10K10
5 Stainless Steel 13K4 13K4 13K2 13K2 13K2
Electrical Data – All Models
Repair Parts List – RJSP
Engineering Data
Model HP Ph/Hz Suction Discharge Wt. lbs.
75RJSP
3
⁄4 48
100RJSP 1 52
150RJSP 1
1
⁄2 1/60 1
1
⁄2” NPT 1
1
⁄2” NPT 60
200RJSP 2 65
300RJSP 3 76
Engineering Data
