ITT Goulds Pumps IC User Manual (English)

Questions and Answers:

I
Isabel GreerAug 16, 2025
How to fix an ITT Goulds Pumps IC that is not delivering liquid?
- J
  Jamie TerryAug 16, 2025
  If your ITT Water Pump isn't delivering liquid, several issues could be the cause. First, the pump might not be primed; re-prime it, ensuring the pump and suction line are full of liquid. Second, the suction line could be clogged; remove any obstructions. Third, the impeller might be clogged; back-flush the pump to clean it. Also, check that the shaft rotation matches the arrow on the bearing housing or pump casing, and ensure the foot valve or suction pipe opening is sufficiently submerged, consulting an ITT representative for the correct depth and using a baffle to eliminate vortices. Finally, the suction lift might be too high; shorten the suction pipe.
E
Edward ReynoldsAug 19, 2025
Why is my ITT Goulds Pumps IC Water Pump so noisy and vibrating?
- B
  brianna40Aug 19, 2025
  If your ITT Water Pump is noisy or vibrating, it could be due to a few reasons. The pump and driver might not be aligned properly, so realign them. The impeller might be partly clogged; back-flush the pump to clean the impeller. Alternatively, the impeller or shaft might be broken or bent, requiring replacement.
A
April DavisAug 22, 2025
What to do if my ITT Goulds Pumps IC Water Pump is not producing the rated flow?
- L
  Lawrence MarshallAug 22, 2025
  If your ITT Water Pump isn't producing the rated flow or head, there are several potential causes. Check for air leaks in the gasket, O-ring, or stuffing box; replace or readjust the mechanical seal and re-prime the pump. The impeller might be partly clogged; back-flush the pump to clean it. Ensure sufficient suction head by fully opening the suction-line shutoff valve and clearing any obstructions. Adjust excessive clearance between the impeller and pump casing. Finally, inspect the impeller for wear or breakage and replace if necessary.
S
Sherry DavisAug 25, 2025
Why are the bearings on my ITT Goulds Pumps IC running hot?
- G
  graynancyAug 26, 2025
  If the bearings on your ITT Water Pump are running hot, several factors could be responsible. First, the pump and driver may not be aligned properly; realign them. Second, there might not be sufficient lubrication; check the lubricant for suitability and level. Third, the lubrication may not be cooled properly; check the cooling system.
D
Daniel KleinAug 27, 2025
Why does my ITT Water Pump start and then stop pumping?
- W
  wendyoconnellAug 28, 2025
  If your ITT Water Pump starts and then stops pumping, it could be due to a few reasons. The pump might not be primed; rearrange the piping to eliminate air pockets. The suction line might have air or vapor pockets, or an air leak; in both cases, repair the leak.
R
Roy ParkerAug 30, 2025
What causes excessive shaft end play in an ITT Goulds Pumps IC?
- E
  Eric RodriguezAug 30, 2025
  Excessive shaft end play in your ITT Water Pump may be caused by the internal clearance of the bearings exceeding the recommended amount; replace the bearings with a bearing of the correct type. Alternatively, the snap ring could be loose in the bearing-housing groove; re-seat the snap ring.
J
Jessica ZimmermanSep 2, 2025
What to do if there is excessive shaft and sleeve runout in ITT Goulds Pumps IC Water Pump?
- M
  Michael SwansonSep 2, 2025
  If there is excessive shaft and sleeve runout in your ITT Water Pump, it could be due to a worn sleeve, in which case you should replace the sleeve. Another possibility is a bent shaft, which would also require replacement.
M
Maria RobertsSep 4, 2025
What causes excessive bearing-frame flange runout in ITT Goulds Pumps IC?
- C
  Connor JonesSep 4, 2025
  Excessive bearing-frame flange runout in your ITT Water Pump may be due to a bent shaft, which requires replacing the shaft. Another cause could be a distorted flange of the bearing frame, which requires replacing the bearing-frame flange.
K
Katie MunozSep 7, 2025
What causes excessive frame-adapter runout in ITT Goulds Pumps IC Water Pump?
- M
  Ms. Kathleen Stone DVMSep 8, 2025
  If there is excessive frame-adapter runout in your ITT Water Pump, it could be due to corrosion on the frame adapter, requiring replacement of the frame adapter. Another possibility is that the adapter-to-frame gasket is not seated properly; re-seat the frame adapter and ensure the adapter-to-frame gasket is seated properly.
P
petersonmelissaSep 10, 2025
What causes excessive seal chamber runout in ITT Goulds Pumps IC Water Pump?
- T
  Tina ParkerSep 10, 2025
  If there is excessive seal chamber or stuffing-box cover runout in your ITT Water Pump, it could be because the seal chamber or the stuffing-box cover is not properly seated in the frame adapter; re-seat the seal chamber or stuffing-box cover. Alternatively, there might be corrosion or wear on the seal chamber or stuffing-box cover, requiring replacement of the seal chamber or stuffing-box cover.

ITT Goulds Pumps IC Specifications

General

Seal Type	Mechanical Seal
Casing Material	Cast Iron
Head	Up to 400 feet
Inlet/Outlet Size	1. 5" to 8"
Material	Cast Iron, Stainless Steel
Temperature Range	-20°F to +250°F

Summary

Introduction and Safety

1.1 Introduction

Purpose of the manual and how to request additional information.

1.2 Safety

Critical safety warnings, hazard levels, terminology, and symbols for safe operation.

1.3 Product Approval Standards

Details regular and explosion-proofing standards for product compliance.

1.4 Product Warranty

Outlines coverage, limitations, and claim process for product warranty.

1.5 ATEX Considerations and Intended Use

Special care for explosive atmospheres and ATEX conformance requirements.

Transportation and Storage

2.1 Transportation and Storage

Guidelines for inspecting, transporting, and storing the product safely.

Product Description

3.1 General Description

Overview of the pump's construction, casing, impeller, seal chamber, and power end.

3.2 Nameplate Information

Details the fields and explanations found on the pump's nameplate.

Installation

4.1 Pre-installation

Precautions, pump location, and foundation requirements before installation.

4.2 Baseplate-mounting procedures

Methods for mounting the baseplate using shims, jackscrews, spring, or stilt.

4.3 Install the Pump, Driver, and Coupling

Steps for mounting the pump and driver onto the baseplate and installing the coupling.

4.4 Pump-to-Driver Alignment

Procedures for checking and performing pump-to-driver alignment for optimal performance.

4.5 Grout the Baseplate

Step-by-step instructions and required equipment for grouting the baseplate.

4.6 Piping Checklists

Guidelines and checks for suction, discharge, bypass, and auxiliary piping.

Commissioning, Startup, Operation, and Shutdown

5.1 Preparation for Startup

Crucial steps and warnings before initiating pump startup.

5.2 Remove the Coupling Guard

Detailed instructions for safely removing the coupling guard.

5.3 Check the Rotation

Procedure to verify the correct direction of pump rotation.

5.4 Couple the Pump and Driver

Steps for correctly coupling the pump and driver.

5.5 Install the Coupling Guard

Instructions for securely installing the coupling guard.

5.6 Bearing Lubrication

Requirements and procedures for lubricating pump bearings with oil or grease.

5.7 Shaft-Sealing Options

Overview of mechanical seal and packed stuffing box options and their connections.

5.8 Pump Priming

Methods for priming the pump, with suction supply above or below the pump.

5.9 Start the Pump

Essential checks and procedures to follow before and during pump startup.

5.10 Limits of Operation

Defines flow limits and permitted number of starts for the pump.

5.11 Pump Operation Precautions

General considerations and warnings for safe pump operation.

5.12 Shut Down the Pump

Steps and precautions for safely shutting down the pump.

5.13 Make the Final Alignment of the Pump and Driver

Procedures to perform final alignment check at operating temperature.

Maintenance

6.1 Maintenance Schedule

Outlines routine, three-month, and annual inspection tasks.

6.2 Bearing Maintenance

Procedures for bearing lubrication, oil changes, and grease requirements.

6.3 Shaft Seal Maintenance

Maintenance procedures for mechanical seals and packed stuffing boxes.

6.4 Disassembly

Precautions, tools required, and steps for disassembling the pump.

6.5 Pre-assembly Inspections

Guidelines for inspecting parts before reassembly, including replacement criteria.

6.6 Reassembly

Step-by-step instructions for assembling pump components.

Troubleshooting

7.1 Operation Troubleshooting

Common operational symptoms, their causes, and remedies.

7.2 Alignment Troubleshooting

Troubleshooting steps for alignment issues with the pump and driver.

7.3 Assembly Troubleshooting

Identifies common assembly problems and their solutions.

Local ITT Contacts

10.1 Regional Offices

Contact information for ITT regional offices worldwide.
