ITW Mima ECOMAT PLUS - 1.1.3 Tensioning Pre-Stretch Toothed Belt

1.1.3 Tensioning the pre-stretch toothed belt
(Ecomat Plus)
Phase 1
Open the service hatch by opening two fastening screws
Phase 2
Loosen the fastening screw of tensioning unit and pull the tensioning
unit
Phase 3
Tight the screw when belt is tense
10
