On left: Upper bearing unit of the pre-stretch roller
On right: Lower bearing unit of the pre-stretch roller (bearing
bushing)
1.1.5 Adjusting the dancing roller tension (Ecomat Plus)
Loosen the fastening nut (1) by turning it to anti clockwise direction
Turn the adjustment screw (2) to clockwise direction, to increase
dancing roller tension
Turn the adjustment screw (2) to anti clockwise direction, to
decrease dancing roller tension
1
2
14
