ITW Diagraph PA/6000 User Manual

Diagraph - an ITW Company PA/4600 & PA/6000 User Manual
Maintenance Page 43
Maintenance
6.3 Recommended Spare Parts List
Part Number Description
DOCUMENTATION
4600‐010 PA/4600&PA/6000UserManual
4600‐015 ServiceToolSoftware
SATO Lt408 PRINTER
4600‐800 SATOLt408PrintEngine(EntirePrinter)
4600‐810 SATOLt408PrintHead
4600‐811 SATOLt408PlatenRollerAssy
4600‐812 SATOLt408FeedRollerAssy
4600‐813 SATOLt408RibbonRollerAssy
4600‐814 SATOLt408GapSensorAssy.
4600‐815 SATOLt408MainPCB
4600‐816 SATOLt408MotorDrivePCB
4600‐817 SATOLt408PowerSupply
4600‐818 SATOLt408LCDPCB
4600‐819 SATOLt408TimingBelt218mm(RibbonDrive)
4600‐820 SATOLt408TimingBelt260mm(StepperMain)
4600‐821 SATOLt408TimingBelt186mm(PlatenDrive)
4600‐822 SATOLt408RibbonSensor
4600‐823 SATOLt408TorqueLimiter(ribbontake‐up)
4600‐824 SATOLt408TorqueLimiter(ribbonsupply)
4600‐825 SATOLt408Rollerbearing(allrollers)
SATO 84xx Se Engines
6000‐6152‐091 EngineAssembly,Sato8485SE
6000‐6152‐092 EngineAssembly,Sato8490SE
6000‐6152‐091 EngineAssembly,Sato8460SE
Zebra PAX Engines
6000‐6153‐091 EngineAssembly,Zebra112PAX4
6000‐6153‐092 EngineAssembly,Zebra113PAX4
6000‐6153‐089 EngineAssembly,Zebra172PAX4
6000‐6153‐090 EngineAssembly,Zebra173PAX4
