Diagraph - an ITW Company PA/4600 & PA/6000 User Manual
Introduction Page 4
Introduction
1.5 Specifications
General Specifications
Category Parameter
Dimensions
(with Yoke)
31 in. (79 cm) L x 23 in. (58.5 cm) H x
25 in. (63.5 cm) D
Weight 90 lbs (41
kg
) (includes yoke, no stand)
Accuracy ±0.06 in. (
±1.6 mm
)
Certifications Œ, CSA, FCC approved, ETL Listed (UL 60950)
Supply Roll Capacity
PA/4600
PA/6000
13 in. (
330.2 mm
)
14 in. (
355.6 mm
)
Label Length 0.5 in. (
12.7 mm
) Min. to 22.0 in. (
558.8 mm
) Max.
Label Width 0.5 in. (
12.7 mm
) Min. to 4.0 in. (
101.6 mm
) Max.
Product Rate
PA/4600
PA/6000
50 PPM Max.
110 PPM Max.
Temperature 41°F - 104°F (5°C - 40°C)
Humidity 10 to 85% RH, Non-Condensing
Electrical Specifications
Category Nominal Minimum Maximum
AC Voltage
Supply
100 - 240 VAC,
1.6A 50/60 Hz
90 VAC
47 Hz
264 VAC
63 Hz
Product Detector Low: 0 to 3 VDC
High: 3 to 5 VDC
Supplies 24VDC
0 VDC 24 VDC
Product Detector
Pulse Width
10 mS 1 mS Infinite
Auxiliary Output
Warning Tower
0 and 24 VDC
1 Amp sinking
0 VDC
0 mA
24 VDC
1.5 Amps sinking
Discrete Inputs
(Optional)
Low: 0 to 10 VDC
High: 10 to 24 VDC
0 VDC 26 VDC
Discrete Input
Pulse Width
Detection
10 mS
3 mS Infinite
Discrete Outputs
(Optional)
0 - 24 V AC/DC at
150 mA
0 V AC/DC,
13 ohms
30 V AC/DC at
170 mA
To Next Page
