Control unit:
71 ESC key
72 ENTER key
73 START key
74 Start LED
75 STOP key
76 + key
77 – key
78 Settings key
79 Cursor key right
80 Cursor key left
81 Information key
82 Program 1
83 Program 2
84 Program 3
85 Program 4
86 Next program
87 Open furnace head
88 Close furnace head
8
4
44
3
100 Programat firing tray
101 Metal pin A
102 Metal pin B
103 Metal pin C
100
101
103
102
