IVT Greenline HT PlusC User Manual

40
INDEX
Technical information
The heat pump's factory settings
The table shows the factory settings for all the settings that can be
changed by the installer.
Sensor table
The table shows all sensor resistance
at different temperatures.
Temperature (ºC) kΩ
-40 154.300
-35 111.700
-30 81.700
-25 60.400
-20 45.100
-15 33.950
-10 25.800
-5 19.770
0 15.280
5 11.900
10 9.330
15 7.370
20 5.870
25 4.700
30 3.790
35 3.070
40 2.510
45 2.055
50 1.696
55 1.405
60 1.170
65 0.980
70 0.824
75 0.696
80 0.590
85 0.503
90 0.430
Menu Setting Factory setting
1.1 Temp. incr. / decr. 4
1.2 Temp. fi ne-tune 0º
1.3 Adapting the heat curve 0º
1.4 Heat curve hysteresis 5º
1.5 Mix. valve incr/decr 4
1.6 Mix. valve fi ne-tune 0º
1.7 Adapting the mixing valve curve 0º
1.8 Mixing valve curve neutral zone 3º
1.9 Mixing valve curve max at GT4 60º
1.10 Setting the room temperature 20º
1.11 Setting the room sensor infl uence 5
1.12 Setting of holiday function 0 days
1.13 Remote control temperature Not active
1.14 Setting of summer disconnection 18º
2.1 Number of hours for extra hot water 0 hours
2.2 Interval for hot water peak Not active
2.3 Setting of hot water temperature 51º
2.4 Setting of DHW hysteresis 4º
4.1 Clock setting HP accord. to clock Not active
4.1.1 Setting level heat pump +/- 0º
4.2 Clock setting additional heat according to clock Not active
4.3 Clock setting hot water according to clock Not active
5.2 Select connection capacity electric cassette 2/3
5.4 Select function only add. heat off
5.5 Select function additional heat yes
5.7 Select external controls 0
5.10 Select operation alt. P2 P2 cont. operat.
5.11 Select operation alt. P3 P3 with comp.
8.1 Setting additional heat timer 60 minutes
