41
INDEX
Technical information
Technical information
Model Greenline HT Plus 6 C/E 7 C/E 9 C/E 11 C/E 14 E 17 E
Emitted /Supplied output at 0/35°C
1
kW 5.9/1.3 7.3/1.6 9.1/2 10.7/2.2 14.4/3.1 16.7/3.7
Emitted /Supplied output at 0/50°C
1
kW 5.4/1.7 6.9/2.1 8.4/2.6 10.1/3.0 13.9/4.2 16.2/4.9
Minimum fl ow heating medium
1
l/s 0.14 0.18 0.22 0.26 0.35 0.40
Nominal fl ow heating medium l/s 0.20 0.25 0.31 0.37 0.50 0.57
Permitted ext. pressure drop heating
medium at nominal fl ow
kPa 36 36 34 33 54 51
Nominal fl ow cooling medium l/s 0.30 0.38 0.46 0.57 0.78 0.90
Permitted ext. pressure drop cooling
medium at nominal fl ow
kPa 49 45 44 80 74 71
Max pressure radiator system bar 1.5
Max press. cooling medium system bar 4
Highest outg. heating medium temp. °C 65
Operating temperature heat transfer
system
°C -5 to +20
Integrated heat/HTF pump Yes
Electrical connection 400V, N3-Phase
Add. heat reconnectable kW 3.0 / 6.0 / 9.0
Recommended fuse size depends on
electrical additional heat
Electric cassette 6 kW
Electric cassette 9 kW
AT 16 16 20 25 25 25
AT 20 25 25 25 32 32
Compressor Scroll
Refrigerant R407C kg 1.35 1.4 1.5 1.9 2.2 2.3
Connection. heating medium Cu/DN 22 22 22 22 28 28
Connection. cooling medium Cu/DN 28 28 28 28 35 35
Dimensions E-model (WxDxH) mm 600x600x1520
Weight E-model kg 146 152 155 170 190 195
Dimensions C-model (WxDxH) mm 600x600x1800
Weight C-model
Copper/Stainless hot w cylinder kg 230/200 231/201 240/210 218 - -
Integrated double-shelled hot w cyl. on
the C-model. Copper or stainless*
Copper /
stainless
Copper /
stainless
Copper /
stainless
Stainless - -
Domestic hot water C-model litres 165 165 165 165 - -
Control unit Rego 637
1
Output data at 0/35°C and 0/50°C and min heating medium fl ow are stated according to the European standard EN 255.
Additional heat not included.
* Anode included in C-models with stainless hot water cylinder.
