MONITOR DESCRIPTION
16 Model 7600/7800 Operation Manual
6.9 Menu Structure
MEASURE
IMPEDANCE
MAIN MENU:
DISPLAY ECG OPTIONS FREEZE PRINT
MENU MENU MENU DIRECT
TRIGGER SIZE Date/Time QRS VOL
AUTO 10 MM/MV OFF
NEXT
SECOND FILTER
ALARM
VOL
LEAD I ON ↑ MEDIUM
SPEED P-LOCK ↓ REC MODE CLEAR
25 MM/SEC ON DIRECT MEMORY
Alarm
Limits
TEST PACER DET MODE COPY TO
MENU ON LOW ADULT USB DRIVE
MAIN MAIN ↑ MAIN MAIN
MENU MENU MENU MENU
↓
HIGH
SIM RATE ↑ USB
OFF MENU
↓
FINE TUNE
↓
FINE TUNE
↑
INTERNAL
TEST OFF
MAIN
MENU
KEY SELECTIONS
DISPLAY MENU OPTIONS MENU
Trigger: Lead I – II – III – AUTO QRS Volume: Off, Low, High
Second: Lead I – II – III Alarm Volume: Low, Medium, High
Speed: 25mm/s and 50mm/s Recorder Mode: Direct, Timed, Delay
Mode: Adult, Ped/Neo
ECG MENU
Size: 5, 10, 20, 40mm/mV
Filter: On, Off Model 7800 Only Selections:
P-Lock: On, Off Measure Impedance
Pacer Detect: On, Off USB Menu
