TROUBLESHOOTING
40 Model 7600/7800 Operation Manual
15.0 TROUBLESHOOTING
Problem
Verify that:
• Unit does not turn on.
 Power cord is plugged into the monitor and the ac outlet.
 Fuses are not blown.
 The ON switch is pressed.
• Trigger pulse is not functional
 ECG size is optimal (select Lead II or AUTO)
• Erratic ECG waveform. Heart Rate is
not counting.
 ECG waveform has enough amplitude (Select Lead II or
AUTO).
 Electrodes placement (see ECG section for proper
placement diagram).
 ECG electrodes have enough conductive gel.
 Measured Impedance < 50kΩ.
