J.P. Instruments EDM-800

Page 34 Engine Data Management
T, A
EGT, CHT
I340
376
EGT, left, CHT, right. Dot
indicates cylinder
T, A
TIT, Turbine Inlet
Temperature
I370
I3.5
Turbine #1, left and fuel flow
right
T, A
Oil Temperature
I 7 8
OIL
T, A
Shock Cooling
-30
CLD
Dot indicates fastest cooling
cylinder
