For Your Safe Flight Page 51
CARB? CARB? N ⇔
CARB? Y
Y—Yes—carbureted
engine
RECRD? RECRD? Y⇔
RECRD? N
Long Term Memory.
Y—only data recording.
N—only real-time data
output.
CYL=6 CYL=4 … CYL=I 2
(EDM-800 only) Set the
number of cylinders. See
page 48 for exceptions.
END Y ⇔ END N
Y—Yes to exit; N—No to
review list again
MAP, Fuel Flow Alarm Limits, Units, Fuel Capacity
MAP Overboost Alarm
Enter the redline for overboost on turbocharged engines.
Fuel Flow Units
Selects the units in all parameters where fuel quantity or fuel rate is
displayed. If you change this parameter, it does not change the numerical
value of the fuel tank capacity. You must do this manually. For example
if you change from Gal. to Lbs., the tank capacity will be interpreted as
50 Lbs. rather than 50 gallons; the EDM will not convert 50 Gal to
equivalent pounds.
Main Tank Capacity
Enter the total capacity of the main tanks in the fuel flow units selected.
If you have tank tabs (but no auxiliary tanks) and sometimes fill only to
the tabs, set the main tank capacity to the capacity up to the tabs.
Auxiliary Tanks
If you do not have auxiliary tanks or tank tabs, answer “No.” If you
answer “Yes,” you will be asked to input the capacity of the auxiliary
tanks in the fuel flow units selected. If you have tank tabs and sometimes
fill only to the tabs, set the auxiliary tank capacity to the difference
between full tank capacity and tab capacity. The EDM does not
differentiate fuel flow between the main and auxiliary tanks; it tracks
only total fuel in the aircraft.
