MAINTENANCE MANUAL
FOR
JABIRU 2200 AIRCRAFT ENGINE
JABIRU 3300 AIRCRAFT ENGINE
DOCUMENT No. JEM0002-5
DATED: 2
nd
June 2015
This Manual has been prepared as a guide to correctly operate, maintain and
service Jabiru 2200 & 3300 engines.
It is the owner's responsibility to regularly check the Jabiru web site at
www.jabiru.net.au for applicable Service Bulletins and have them
implemented as soon as possible. Failure to do this may render the
aircraft un-airworthy and void Jabiru’s Limited, Express Warranty.
This document is controlled while it remains on the Jabiru server. Once
this no longer applies the document becomes uncontrolled.
Every effort is made to ensure that the information provided is accurate and up to date. However,
there is an inherent risk in the use of Jabiru® engines in aircraft and in the operation of aircraft
generally. The operator of any type of aircraft powered by Jabiru® engines assumes any and all
risk relating to such use. Accordingly, use of the information herein is at the user's risk and Jabiru
disclaims any responsibility for any errors or omissions. In the event that you have any questions
or concerns with regard to any information herein, please contact Jabiru Aircraft Pty Ltd.

Table of Contents

Other manuals for Jabiru 3300

Preview: Overhaul Manual
Overhaul Manual201 pages
Preview: Installation Manual
Installation Manual56 pages
Preview: Instruction And Maintenance Manual
Instruction And Maintenance Manual103 pages

Questions and Answers

  • M
    Michael MillerAug 22, 2025
    Why is my Jabiru Engine running too hot?
    • F
      fletcherkennethAug 22, 2025
      If your Jabiru Engine runs too hot, with oil temperature above 110°C (230°F), there are several possible causes. Check the oil level; too much or too little oil in the crankcase can cause overheating, so adjust as necessary. Poor quality oil can also lead to this issue, so consider an oil change using the specified oil. A clogged oil filter restricts oil flow, so change the filter. Excessive piston blow-by, often due to worn or sticking piston rings, may require a complete engine overhaul. Faulty bearings can also contribute to overheating; if metallic particles are present in the oil, a complete engine overhaul is necessary. Lastly, a faulty oil temperature gauge can give a false reading, so consider exchanging the gauge.
  • W
    William BrowningAug 27, 2025
    Why does my Jabiru Engine run erratically or misfire occasionally?
    • P
      pfreemanAug 28, 2025
      If your Jabiru Engine runs erratically or misfires occasionally, consider these possible causes: * **Spark plug failure:** Check the plugs, clean inside and outside, and adjust the electrode gap. If necessary, replace the plugs. * **Faulty HT leads:** Dry any damp leads and replace damaged leads. * **Faulty ignition unit:** Replace the ignition unit. * **Clogged fuel filter:** Replace the fuel filter.
  • M
    Matthew Golden DVMAug 29, 2025
    What to do if my Jabiru Engine runs erratically?
    • F
      fvalentineAug 29, 2025
      If your Jabiru Engine is running erratically or misfiring occasionally, there are a few potential causes. Start by checking the spark plugs. Clean them inside and out, adjust the electrode gap, and replace if necessary. Inspect the high tension (HT) leads; dry any damp leads and replace any that are damaged. A faulty ignition unit can also cause misfires, so consider replacing it. Ensure the fuel filter isn't clogged by renewing it. Finally, check that the carburettor sense tube is connected; this tube helps control the fuel mixture and should connect the small nipple on the carburettor to a fitting in the filtered side of the carburettor heat box.
  • K
    Kathryn ShieldsAug 31, 2025
    Why is the oil pressure low on my Jabiru 3300?
    • L
      Lori WilliamsAug 31, 2025
      If the oil pressure in your Jabiru Engine is low, start by checking the oil level in the sump and replenish as necessary. High oil temperature can also cause low oil pressure, so ensure the engine isn't overfilled with oil and check for proper installation gaps to maintain airflow. Inspect the pressure gauge, sender, and wiring for faults, and renew as necessary. Faulty crankshaft bearings can lead to low oil pressure, potentially requiring an engine overhaul. Lastly, inspect the relief valve for proper sealing; foreign matter stuck in the valve can cause low pressure, so clean and replace it.
  • M
    Miranda NealSep 2, 2025
    Why does my Jabiru 3300 Engine keep running with the ignition off?
    • S
      Steven ShafferSep 2, 2025
      If your Jabiru Engine continues to run even after the ignition is turned off, several issues might be responsible. First, check the idle speed and adjust it to the proper level (900 RPM). A faulty ignition switch can also cause this problem, so inspect the switch and cables, repairing or replacing them as necessary. Finally, an overheated engine can continue running, so conduct a cooling run at 900 RPM to address this.
  • M
    marcuswoodsSep 3, 2025
    Why is my Jabiru 3300 Engine idling unsteadily with smoky exhaust?
    • M
      Marc StoneSep 4, 2025
      If your Jabiru Engine idles unsteadily after the warm-up period and produces smoky exhaust, there are a few potential causes. Ensure the choke is fully closed, as an activated choke can cause these symptoms. A dirty, jammed, or worn float valve can also lead to unsteady idling, so clean or renew the float valve. Lastly, check for an intake manifold leak, tightening all connections and replacing any faulty items.
  • B
    Brent SmithSep 5, 2025
    What causes a CHT reading error on a Jabiru 3300 Engine?
    • J
      jason10Sep 5, 2025
      If you're experiencing a CHT (Cylinder Head Temperature) reading error on your Jabiru Engine, start by checking the gauge, sender, and their connections. Replace them with known good items if possible, and try reversing the polarity between the gauge and sender to re-test. Verify the original reading using a second thermometer, such as a hand-held infrared thermometer, to confirm if the temperatures are improper. Also, consider the cold junction temperature; the standard gauges assume the cold junction is around 25°C, so ensure the junction isn't exposed to excessively hot or cold air for best results.
  • S
    Shannon SanchezSep 7, 2025
    Why does the oil collector bottle on the firewall fill quickly in my Jabiru Engine?
    • H
      huntwalterSep 7, 2025
      If you notice the oil collector bottle on the firewall of your Jabiru Engine filling quickly, it could be due to several reasons. Worn, broken, or wrongly fitted piston rings can cause this issue, potentially requiring repair or an engine overhaul. An incorrect oil grade can also contribute, so perform an oil change using the specified oil. Worn or distorted cylinders may also be the cause, again potentially requiring repair or an engine overhaul. Over-filling the sump can lead to this problem, so reduce the oil level in the sump. Finally, negative-g conditions, which the Jabiru Engine is not approved for, or strong turbulence can have a similar effect; reduce RPM/speed when operating in strong turbulence.
  • M
    morgankyleSep 9, 2025
    What causes excessive oil consumption in a Jabiru 3300?
    • A
      Alexander BlakeSep 9, 2025
      Excessive oil consumption in your Jabiru Engine can stem from several causes. Worn, broken, or wrongly fitted piston rings are a primary suspect, necessitating repair or an engine overhaul. Poor oil quality can also contribute, so perform an oil change using the specified oil. Worn valve guides may be the issue, requiring repair of the cylinder head. Lastly, check for any oil leaks and seal them.
  • M
    Makayla GoldenSep 12, 2025
    What causes excessive vibration in my Jabiru 3300?
    • B
      Briana HicksSep 12, 2025
      Excessive vibration in your Jabiru Engine can arise from several sources. Begin by checking if the propeller is out of balance and balance it according to the manufacturer’s instructions. Ensure the propeller tip tracking is within tolerance, adjusting as necessary. Uneven propeller blade pitch can also cause vibration, so check and adjust the blade pitch. Check the spinner for balance and adjust if needed. An unsuitable propeller can lead to vibration, so replace it, with quality 2-bladed fixed pitch wooden types recommended. Incorrect tuning can contribute, so check and adjust the carburettor. Finally, ensure that engine components like air ducts, exhaust, and the oil cooler aren't rubbing on cowls or the fuselage.

Summary

SPECIFICATIONS

OPERATING SPEEDS AND LIMITS

Defines safe operating speeds, temperatures, and pressures for the engines.

TORQUE SPECIFICATIONS

Lists torque values for various fasteners and components.

AIRWORTHINESS LIMITATIONS

OPERATING INSTRUCTIONS

DAILY CHECKS

STARTING PROCEDURE

Provides step-by-step instructions for starting the engine.

CARBURETTOR ICING

MAINTAINER REQUIREMENTS

TORQUE; TENSION WRENCH

Explains the use and importance of torque wrenches for accurate assembly.

TORQUE APPLICATION PROCEDURE

Details the correct technique for applying torque to fasteners.

MAINTENANCE

ENGINE INSPECTION CHART

Presents a chart detailing inspection intervals and tasks.

ENGINE & ENGINE COMPARTMENT - INSPECTION DETAILS

SPECIAL MAINTENANCE - CHECK AFTER INITIAL 5 HOURS - SOLID LIFTER ONLY

SERVICE & REPAIR PROCEDURES

ENGINE TEST RUN

Details the procedure for performing an engine test run.

OIL & FILTER CHANGE

Provides instructions for changing the engine oil and filter.

SPARK PLUGS

CARBURETTOR INSPECTION & ADJUSTMENT

Covers inspection and adjustment of the engine's carburetor.

HEAD BOLT TENSION CHECK

Explains how to check cylinder head bolt tension.

VALVE CLEARANCE ADJUSTMENT (SOLID LIFTER ENGINES ONLY)

COMPRESSION CHECK

PROP STRIKE INSPECTION

Details procedures for inspecting the engine after a propeller strike.

TROUBLE SHOOTING

ENGINE WONT START

ENGINE RUNS TOO HOT - OIL TEMPERATURE ABOVE 110 OC (230 oF)

UNSATISFACTORY POWER OUTPUT

LOW OIL PRESSURE

EXCESSIVE VIBRATION

KNOCKING UNDER LOAD

ENGINE HARD TO START AT LOW TEMPERATURE - COLD START CHECKLIST

IRREGULAR; LOW COMPRESSIONS

Jabiru 3300 Specifications

General IconGeneral
ConfigurationHorizontally opposed
Number of Cylinders6
Cooling SystemAir-cooled
Compression Ratio8.0:1
Firing Order1-4-5-2-3-6
Power Output at RPM120 hp at 3300 RPM
Oil SystemWet sump
Displacement3300 cc
Power Output120 hp
Fuel TypeAvgas 100LL
Engine TypeFour-stroke
Fuel SystemCarburetor
