Engine Maintenance Manual
Jabiru 2200 & 3300 Aircraft Engines
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
L:\files\Manuals_For_Products\Engine_Manuals\Engine Maintenance Manual 22 & 33\JEM0002-5.docx
9.27 Engine Installation
L2 or LAME (A&P or LSA Repairman / Maintenance)
L2 or LAME (A&P or LSA Repairman / Maintenance)
Table 16 – Engine Installation
Fit engine to engine mount
Torque engine mount bolts
7/16 Tube Socket
7/16 Ring Open End Spanner
Fit muffler (if not already fitted) and fit carburettor
heat muff and hose
Connect left and right ignition coils leads
Connect exhaust gas temp (if fitted)
Connect cylinder head sender
Connect oil temp gauge sender
Connect oil pressure gauge sender
7/16 Ring Open End Spanner
Connect Battery (Earth lead first)
10mm Ring Open End Spanner
Fit Propeller and spinner
7/16 Ring Open End Spanner
7/16 Torque Wrench
Phillips Screw Driver
Prime Fuel system with electric pump and inspect for
leaks
Check for oil. Fill if needed.
2200: 2.3L oil (2.43 US quarts)
3300: 3.5L oil (3.7 US quarts)
Wind over to get oil pressure
Start and inspect for leaks
Test Fly
Note: First flight is a test flight: fly conservatively!
Remove Cowls and inspect for anything loose,
rubbing or leaking.
Check Head bolt tensions torqued per Table 10
Carry out checks for first 5, 10 & 25 hours as noted
above (Section 8)
