Jabiru 3300 - 2200 - Dimensions; 2200 - Denomination of Cylinders; Figure 2 - 2200 Engine Dimensions; Figure 3 - 2200 Cylinder Denomination

Engine Maintenance Manual
Jabiru Aircraft Pty Ltd
JEM0002-5
Jabiru 2200 & 3300 Aircraft Engines
This document is controlled while it remains on the Jabiru server. Once this no longer applies the document becomes uncontrolled.
ISSUE
1
2
3
4
5
Dated : 2nd June 2015
Issued By: AS
Page: 22 of 103
L:\files\Manuals_For_Products\Engine_Manuals\Engine Maintenance Manual 22 & 33\JEM0002-5.docx
3.14 2200 – Dimensions
Figure 2 – 2200 Engine Dimensions
3.15 2200 – Denomination of Cylinders
Figure 3 – 2200 Cylinder Denomination
