MLO51206 - 22 -
Technical specifications
AZ-10K GSM control unit
GSM control unit power supply = 5 V 2.5 A max.
Backup battery LI18650 = 3.7 V / 1.8 Ah (usual battery lifetime is approx. 5 years)
The backup time of the control unit is 12 hours
Number of users up to 10 (each may have one RFID tag and one remote control)
Number of detectors up to 10
Number of RFID tag readers 1
Number of doorbell buttons 1
Dimensions 165 x 120 x 40 mm
AZ-10D RFID tag reader
Power supply 2x AAA 1.5V / 1200 mAh alkaline batteries
(battery lifetime is approx.1 year)
Dimensions 80 x 80 x 30 mm
AZ-10P motion detector
Power supply 2x AAA 1.5 V / 1200 mAh alkaline batteries
(battery lifetime is approx.1 year)
Coverage detection angle 120°, covers an area of 10 x 10 m
Dimensions 65 x 95 x 60 mm
AZ-10M door-opening detector
Power supply 2x AAA 1.5 V / 1200 mAh alkaline batteries
(lifetime is approx.1 year)
Reacts to the magnet being withdrawn by 20 mm
Dimensions 32 x 145 x 25 mm + 15 x 55 x 55 mm
AZ-10R remote control
Power supply L1016 6 V alkaline battery (battery lifetime is approx.2 years)
Dimensions 55 x 40 x 15 mm
AZ-10B wireless doorbell button
Power supply L1016 6 V / 35 mAh alkaline battery (lifetime is approx.1 year)
Dimensions 80 x 28 x 16 mm
JA-63ST (10S) wireless combined smoke and heat detector
Power supply 3 x Alkaline batteries type LR6 (AA) 1.5 V
(battery lifetime is approx.2 years)
Reacts to premises filled with smoke, alternatively temperature over 60-65°C
Dimensions diameter 126 mm x 50 mm
Power adaptor
Power supply voltage ~110 - 230 V / 50 Hz, 0.2 A, protection class II;
Output voltage = 5 V , 3 A
