Tempstar HH Series Technical Manual 7610-002-23-32
Issued: 09/14/2007 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
ELECTRICAL REQUIREMENTS
3
TEMPSTAR HH:
RINSE TYPICAL
HEATER TOTAL ELECTRICAL
VOLTS PH HZ RATINGS AMPS CIRCUIT
415 3 60 12KW 28 A 35 AMP
415 3 60 14KW 30 A 40 AMP
208 1 60 12KW@240V 75 A 100 AMP
208 1 60 14KW@240V 82 A 110 AMP
230 1 60 12KW@240V 81 A 110 AMP
230 1 60 14KW@240V 90 A 125 AMP
208 3 60 12KW@240V 48 A 60 AMP
208 3 60 14KW@240V 52 A 70 AMP
230 3 60 12KW@240V 52 A 70 AMP
230 3 60 14KW@240V 57 A 80 AMP
460 3 60 12KW@480V 24 A 30 AMP
460 3 60 14KW@480V 26 A 35 AMP
TEMPSTAR HH NB:
RINSE TYPICAL
HEATER TOTAL ELECTRICAL
VOLTS PH HZ RATINGS AMPS CIRCUIT
208 1 60 N/A 31 A 35 AMP
230 1 60 N/A 33 A 35 AMP
208 3 60 N/A 23 A 25 AMP
230 3 60 N/A 24 A 35 AMP
460 3 60 N/A 10 A 15 AMP
TEMPSTAR HH S:
RINSE TYPICAL
HEATER TOTAL ELECTRICAL
VOL
TS PH HZ RATINGS AMPS CIRCUIT
208 1 60 N/A 12 A 15 AMP
230 1 60 N/A 12 A 15 AMP
208 3 60 N/A 12 A 15 AMP
230 3 60 N/A 12 A 15 AMP
NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical fixed-
trip circuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection than
what is displayed here. Always verify with your electrical service contractor that your circuit protection is adequate
and meets all applicable national and local codes. These numbers are provided in this manual simply for reference
and may change without notice at any given time.
