2-10 4271491-Second Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Repair Specifications
PDU 12 Volt POS Connector Nut (5 and 7) Torque
(See page 4-149.)
lb-ft (N·m) 12.5 (16.9)
PDU 48 VDC BAT POS Connector Nut (6) Torque
(See page 4-149.)
lb-in. (N·m) 80 (9)
PDU 48 VDC BAT Generator Connector Nut (8)
Torque (See page 4-149.)
lb-in. (N·m) 80 (9)
PDU Flange Nut (11) Torque (See page 4-150.)
lb-ft (N·m) 12.5 (16.9)
PDU Flange Nut (12) Torque (See page 4-150.)
lb-in. (N·m) 40 (4.5)
PDU Flange Nut (17) Torque (See page 4-150.)
lb-in. (N·m) 40 (4.5)
PDU Flange Nut (18 ) Torque (See page 4-150.)
lb-in. (N·m) 80 (9)
TCU Wire Connection Nut Torque
lb-ft (N·m) 11 (14.9)
SCU Wire Connection Screw Torque
lb-in. (N·m) 53 (6)
3WD Traction Controller Wire Connection Screw
Torque
lb-in. (N·m) 53 (6)
Contactor Nut (4) Torque (See page 4-167.)
lb-in. (N·m) 35 (4)
Contactor Nut (5) Torque (See page 4-167.)
lb-in. (N·m) 15 (1.7)
Fuse Mounting Flange Nut (8) Torque
(See page 4-167.)
lb-in. (N·m) 80 (9)
Flange Nut (18) Torque (See page 4-167.)
lb-in. (N·m) 40 (4.5)
Fuse Mounting Nut Torque
lb-in. (N·m) 80 (9)
Instrument Panel Mounting Screw Torque
lb-in. (N·m) 130 (14.7)
Rectifier Kit Screw (3 and 9) Torque
(See page 4-180.)
lb-in. (N·m) 30 (3.9)
Rectifier Kit Nut (5) Torque (See page 4-180.)
lb-in. (N·m) 40 (4.5)
Front AC Traction Motor Mounting Screw Torque
lb-in. (N·m) 93 (10.5)
Front AC Traction Motor Wire Connector Nut Torque
lb-ft (N·m) 11 (14.9)
AC Traction Motor (3WD) Mounting Screw Torqu e
lb-ft (N·m) 35 (47.5)
3WD Traction Controller Wire Connection Screw
Torque
lb-in. (N·m) 53 (6)
Brake Coil Mounting Screw Torque
lb-in. (N·m) 65 (7.3)
