Jacobsen Eclipse 322 62800 User Manual

3-4 4271491-Second Edition
GENSET AND BATTERY PACK
3
Repair Specifications
Electric Models
Battery Pack 48V (six 8-volt Trojan T890 deep cycle lead
acid batteries) with single point watering
system
Traction Drive System (All Models)
Traction Drive Motor 48-volt, brushless, keyed shaft
Traction Drive Motor Power Rating
hp (kW) 3 (2.2) continuous
Specification
Fan Belt Deflection with 22 lb (98 N·m) applied at the
midpoint of pulleys
in. (mm) 0.28–0.35 (7–9)
Muffler Mounting Nut Torque
(Diesel Models)
lb-ft (N·m) 7.2–8.3 (9.8–11.3)
Genset Carrier Mounting Screw Torque
(Diesel Models)
lb-ft (N·m) 65.0 (88.0)
Coupling Shaft Mounting Screw Torque
(Diesel Models)
lb-ft (N·m) 13.0 (17.6)
Generator Flange Mounting Screw Torque
(Diesel Models)
lb-ft (N·m) 13.0 (17.6)
Generator Assembly Mounting Screw Torque
(Diesel Models)
lb-ft (N·m) 13.0 (17.6)
Governor Linkage Arm Nut Torque
(Diesel Models)
lb-in. (N·m) 40 (4.5)
Genset Carrier Mounting Screw Torque
(Gasoline Models)
lb-ft (N·m) 65.0 (88.0)
Mounting Flange Screw Torque
(Gasoline Models)
lb-ft (N·m) 32.0 (43.4)
Generator Assembly Mounting Screw Torque
(Gasoline Models)
lb-ft (N·m) 20.0 (27.1)
Engine Mounting Screw Torque
(Gasoline Models)
lb-ft (N·m) 19 .0 (25.5)
Engine Coupler Screw Torque
(Gasoline Models)
lb-ft (N·m) 32.0 (43.4)
