CONTROLS
Lithium
Maintenance Hours
To display maintenance hours, press either of the orange buttons (AM or AN) on the LDU until the maintenance hours
screen is on the LCD display. To reset maintenance hours, press the black button (AL).
Select Units
To set the display units, press either of the orange buttons (AM or AN) on the LDU until the SELECT UNITS? screen is
on the LCD display. Press the black button (AL) to enter set mode. Use the orange buttons to select the desired setting.
• Units must be set to either English or metric.
CFG Reel Direction
To set reel rotation direction, press either of the orange buttons (AM or AN) on the LDU until the reel direction screen is
on the LCD display. Press the black button (AL) to enter set mode. Set reel direction for each reel, pressing black button
to change between each reel. Direction is viewed from front of motor shaft
• ReelCounter-Clockwise (CCW)
• Vertical MowerClockwise (CW) or CCW
Software Code Revision Level
Displays the revision level for software loaded for each controller. This information is shown on two screens. The soft-
ware revision levels may be an aid for service technicians working on the mower.
• The first screen displays the software revision levels for the 3WD (If installed), TCU, and SCU.
• The second screen displays the software revision levels for the MCU, RCU, and LDU.
CAN Network Status
Displays the CAN (Controller Area Network) status for each of the controllers. A steady (non flashing) controller name
indicates CAN traffic has been detected from controller within the last two seconds. A flashing controller name indicates
CAN traffic has not been detected from controller.
Switch Status
Displays the current switch settings, and is used to diagnose switch problems. A status of 0 indicates the switch is in the
OFF position. A status of 1 indicates the switch is in the ON position. Check the wiring and operation of any switch that is
not displaying the correct status.
The switches are broken up into three sets of numbers, with a gap between each set.
• The first set of numbers displays the status of the left, center, and right reel switches (C, D, and E) on the instrument
panel.
• The second set of numbers displays the status of the mow switch (B), light switch (F), horn switch (G), and system
power switch in start position (H).
• The third set of numbers displays the status of the lower and raise switches that are part of the joystick (J), and the
seat switch.
Maximum Mow Speed
To set the maximum mow speed, press either of the orange buttons (AM or AN) on the LDU until the set MAX MOW
SPEED screen is on the LCD display. Press the black button (AL) to enter set mode. Use the orange buttons to raise
(AN) or lower (AM) the maximum mow speed to the desired speed. press the black button to set speed.
• Maximum mow speed must be between 1.0 and 5.0 mph (1.6 and 8.0 kph), and is adjustable in 0.5 mph (0.8 kph)
increments.
