B
CONTROLS
en-31
Safety, Operation, & Maintenance Manual
Lithium
Maximum Transport Speed
To set the maximum transport speed, press either of the orange buttons (AM or AN) on the LDU until the set MAX
SPEED screen is on the LCD display. Press the black button (AL) to enter set mode. Use the orange buttons to raise
(AN) or lower (AM) the maximum transport speed to the desired speed. press the black button to set speed.
• Maximum transport speed must be between 1.0 and 9 mph (1.6 and 14.5 kph), and is adjustable in 0.5 mph (0.8
kph) increments.
Number of Reel Blades
To set the number of blades on each reel, press either of the orange buttons (AM or AN) on the LDU until the reel blades
screen is on the LCD display. Press the black button (AL) to enter set mode. Use the orange buttons to raise (AN) or
lower (AM) the number of reel blades. press the black button to set speed. Entering the wrong number of blades will
affect the fixed FOC setting.The only reels currently available are 7, 9, 11, or 15 blade reels.
2WD/3WD Mode
pressing black button (AL) toggles mower between 2WD and 3WD modes. Do not set mower to 3WD if the 3WD system
is not installed.
Fixed FOC Setting
To set the fixed FOC, press either of the orange buttons (AM or AN) on the LDU until the FOC x.xxx CHANGE? screen
is on the LCD display. Press the black button (AL) to enter set mode. Use the orange buttons to raise (AN) or lower (AM)
the FOC value to the desired setting. press the black button to set speed. The minimum and maximum fixed FOC setting
varies, depending on the number of blades.
See Frequency of Cut on page 34.
15 Blade Reel........... 0.05 - 0.25 in. (0.12 - 0.63 cm)
11 Blade Reel........... 0.05 - 0.25 in. (0.12 - 0.63 cm)
9 Blade Reel............. 0.06 - 0.30 in. (0.15 - 0.77 cm)
7 Blade Reel............. 0.07 - 0.39 in. (0.19 - 0.99 cm)
Factory Reset
To reset controller to factory default values, press either of the orange buttons (AM or AN) on the LDU until the Factory
Reset screen is on the LCD display. Press the black button (AL) to reset values back to factory default settings. All val-
ues saved in mower attachment modes will also revert to their original factory default settings.
Mower Attachment Mode 1 (11 Blade Reel)
Reel Direction........... CW
Reel Speed............... 2200 rpm
Mow Speed .............. 4 mph
Transport Speed....... 9 mph
FOC.......................... 0.160 in.
Reel Blades .............. 11
Display Units ............ English
Backlap Timer .......... 10 Minutes
To Next Page
