en-11
JACOBSEN G-PLEX III Series: FH & FJ
SAFETY AND OPERATORS MANUAL
4.6 SLOPES
DO NOT USE ON SLOPES GREATER THAN 15°
The slope 15° was calculated using static stability
measurements according to the requirements of
EN 836.
4.5 VIBRATION LEVEL
When the machine was tested for hand/arm
vibration levels. The operator was seated in the
normal operating position with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
The Machinery Safety Directive 98/37/EC
By compliance to:
The Lawnmower Standard EN836:1997
Referenced to hand/Arm: EN1033:1996
Information Supplied for Physical Agents
Directive 2002/44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2001)
When the machine was tested for Whole Body
vibration levels. The operator was seated in the
normal operating position with both hands on the
steering mechanism. The cutting device was
rotating with the machine driven in a straight line at 6
Km/hr on a level freshly cut lawn.
The Machinery Safety Directive 98/37/EC
By compliance to:
Whole Body EN1032:2003
Information Supplied for Physical Agents
Directive 2002/44/EC
By reference to:
Whole Body Standards BS EN ISO 2631-1 (1997)
IIIxelP-GnesbocaJ
JF,HF:seireS
noitareleccAmrA/dnaH
level
HRroHLxaM
s/msnoitareleccA
2
qeAZ,Y,XfoeulaVnaeM
05.0
IIIxelP-GnesbocaJ
JF,HF:seireS
noitareleccAydoBelohW
level
tooFHRroHLxaM
s/msnoitareleccA
2
qeAZ,Y,XfoeulaVnaeM
61.1
IIIxelP-GnesbocaJ
JF,HF:seireS
noitareleccAydoBelohW
level
noitacoLtaeS
s/msnoitareleccA
2
qeAZ,Y,XfoeulaVnaeM
58.0
4 SPECIFICATIONS
ERUTAREPMETYTISOCSIVLIO
)F°93(C°4EVOBA03EAS
)F°93(C°4WOLEB03-W01ro03-W5EAS
4.7 RECOMMENDED LUBRICANTS
Engine oil:
Diesel: Should be to MIL-L-2104C
or to A.P.I. Classification CD
Gasoline: A.P.I. Classification SE/SF
Hydraulic Oil: GreensCare 46
Grease: K NATE (RJL No. 4213860), or
equivalent to MIL-G-23549C,
MIL-G-2345C, DIN 51 825,
DIN 51 818.
