JACOBSEN G-PLEX III Series: FH & FJ
SAFETY AND OPERATORS MANUAL
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
BG Black Green
BO Black Orange
NU Brown Blue
WG White Green
WY White Yellow
1 Ground Point
2 Main Starter Terminal
3 Starter Solenoid
4 Alternator
5 Key Switch
6 Fuse Box
7 Logic Controller (Black)
8 Logic Controller (Gray)
9 Battery
10 Hour Meter
11 Alarm Light
12 Alarm Buzzer
13 Reel Enable Switch
14 Light Switch
15 Starter Relay
16 Engine Stop Relay#
17 Engine Ground
18 Accessory Socket
19 Foot Switch
20 Paddle Switch
21 Seat Switch
22 Parking Brake Switch
23 Lower Solenoid
24 Raise Solenoid
25 Cut Solenoid
26 Backlap Switch
30 Oil Light Switch
32 Working Light
33 Working Light
34 Air Seat Connector
35 Engine Kill
36 Carburettor Solenoid
37 Program Port
38 Reel Interlock Switch
40 Can Adaptor
41 Splicers
Logic Controller (Black)
7a Engine Water Temperature Input
7b Raise Lower Input
7c Glow Plug Output
7d Start Solenoid Output
7e Fuel Solenoid Output
7f Alarm Lamp Output
7g Raise Solenoid Output
7h Lower Solenoid Output
7j Cut Solenoid Output
7k Alarm Buzzer Output
7l Power 12V +
7m Power 12V +
Logic Controller (Gray)
8a Power Ground
8b Power 12V +
8c Channel H
8d Channel L
8e Start / Stop Cutter Input
8f Starter Input
8g Seat Switch Input
8h Sensor Power Supply
8j Sensor Ground
8k Backlap Input
8l Parking Brake Input
8m Engine Oil Pressure Input
11.2 ELECTRICAL CIRCUIT - GASOLINE
11 SCHEMATICS
