Jacobsen LF 4677

61
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
132647 1 Valve, Shut Off
2 3001279 1 Switch, Float
3 3002397 1 Plug, Magnetic
339899 1 • O-Ring
4 3009204 1 Fuel Tank
5 3005871 1 Hydraulic Tank
6 3005872 1 Shell, Tank Cover
7 3006243 2 Plate, Tank Mounting
8 3009347 1 Strainer, Fuel Filler
9 3006332 1 Breather Filter
10 3006337 1 Fuel Sender
11 5003374 1 • Gasket
12 3006067 1 Cap, Fuel Tank
13 554748 1 Fuel Line, 5/16” I.D. Cut to 65 Inches
14 554748 1 Fuel Line, 5/16” I.D. Cut to 18 Inches
15 361117 3 Bushing, Fuel Tank
16 361748 1 Valve, Overflow
17 554752 1 Fuel Line, 3/16 I.D. Cut to 65 Inches
18 366526 6 Clamp, Hose
19 400106 14 Screw, 1/4-20 x 5/8” Hex Head
20 403910 5 Screw, #10-24 x 1/2” Truss Head
21 404016 5 Screw, 1/4-20 x 5/8” Truss Head
22 446130 14 Lockwasher, 1/4 Heavy
23 452004 14 Flat Washer, 1/4
24 446118 5 Lockwasher, #10 Heavy
25 2810702 1 Valve, Needle
