JACOBSEN TR3
SAFETY, OPERATORS & MAINTENANCE MANUAL
5 DECALS
5.1 SAFETY DECALS EC
A. 009034910 Read Operator's Manual.
B. 009034890 Keep a Safe Distance from
the Machine.
C. 009034920 Stay Clear of Hot Surfaces.
D. 009034880 Do Not Open or Remove
Safety Shields While the
Engine is Running.
E. 009034940 Caution Rotating Blades.
F. 009034930 Avoid Fluid Escaping Under
Pressure. Consult Technical
Manual for Service
Procedures.
G. 009034900 Do Not Remove Safety
Shields While Engine is
Running.
H. 009114100 Danger of Explosion if the
Battery Terminals are Short
Circuited.
J. 009114160 Maximum permissible
working slope.
K. 4133706 Caution Diesel Fuel
L. 4133705 Caution Hydraulic Oil
M. 4118415 Caution Engine Coolant
under Pressure
N. 4153197 Caution, Stop Engine &
Remove the Starter Key
Before Pressure Washing
ABCD
E
FG H
JKLM
5.2 INSTRUCTION DECALS EC
Description
A. Maximum Sound Power Level
B. Ignition Switch
C. Throttle Control
D. Cutting Unit Lift
E. Fwd/Rev Traction Pedal
F. Weight Transfer
G. Parking Brake
H. Jacking Point
J. Slinging Point
A
E
B
G
F
TC
C
D
H
J
4153197
N
