3 CONTROLS
3.1 ICONS ___________________________________________________________________
WARNING
Never attempt to drive the mower unless you have read the Safety and Operation Manual
and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all of the controls and gauges before operating this mower.
Coolant
Temperature
D
Read Manual Engine Throttle
High Low
Hour Meter
Parking Brake
Engaged Disengaged
Fuel
Gasoline Diesel
Reel / 3WD Switch
Enable Disable
Choke
Engine
Off Run Start
Glow Plug
On Off
Reel Rotation
Forward Reverse
Circuit Breaker
