J-200
All North American J-235/J-245/J-275/J-280 Models (60 Hz)
240V/40A* 240V/50A** 240V/60A***
Circuit Breaker (2-Pole): 40A* 50A** 60A***
Number of Wires: 3 3 3
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 26A 36A 45A
*
In 40A conguration, the heater will not operate while either jets
pump is running in high speed. Note: pump 2 runs only in high
speed.
**
In 50A conguration, the heater will not operate while both jets
pumps are running in high speed. This is the factory setting.
Note: pump 2 runs only in high speed.
***
In 60A conguration the heater will operate while both jets pumps
are running in high speed.
Export J-235/J-245/J-275/J-280 Models (50 Hz)
230V/20A* 230V/30A** 230V/40A***
Circuit Breaker: 20A* 30A** 40A***
Number of Wires: 3 3 3
Frequency: 50 Hz 50 Hz 50 Hz
Current Draw: 15A 23A 29A
*
In 20A conguration, the heater will not operate while either jets
pump is running in high speed. This is the factory setting. Note:
pump 2 runs only in high speed.
**
In 30A conguration, the heater will operate while one jets pump is
running in high speed. Note: pump 2 runs only in high speed.
***
In 40A conguration the heater will operate while both jets pumps
are running in high speed.
Export J-210 Models (50 Hz)
230V/20A* 230V/30A**
Circuit Breaker: 20A* 30A**
Number of Wires: 3 3
Frequency: 50 Hz 50 Hz
Current Draw: 15A 21A
*
In 20A conguration, the heater will not operate while the jets
pump is running in high speed. This is the factory setting
**
In 30A conguration, the heater will operate while the jets pump is
running in high speed.
13
