Jacuzzi J-385 User Manual

17
J-300
Figure B Control Box
Figure C Connections
(North American 60 Hz
240 VAC Connection Models)
12 3
1. Main Terminal
2. Bonding Lug/Grounding Terminal
3. Power wires entrance (electrical
tting and conduit must be installed)
TB3
TB1
A B C D
OZONE
P1 1SPD
UV
A/V
30A
F2 10A 250VAC
F3 0.125A 240V
30A
FAN
STEP LIGHT
(OPTIONAL)
J37
J44
J73
J72
J74
J35
J59
J51
J33
J36 J46
J41 J47
J49
J38
J53
Green
TB3
TB1
A B C D
OZONE
P1 1SPD
UV
A/V
30A
F2 10A 250VAC
F3 0.125A 240V
30A
FAN
STEP LIGHT
(OPTIONAL)
J37
J44
J73
J72
J74
J35
J59
J51
J33
J36 J46
J41 J47
J49
J38
J53
TB3
TB1
A B C D
OZONE
P1 1SPD
30A
F2 10A 250VAC
J37
J44
J73
J72
J74
J35
J33
J36 J46
J41 J47
J49
J38
J53
Red
Black
DANGER
Turn power off
before servicing. This
task should only be
performed by a quali-
fied technician.
!
RISK OF SHOCK OR
ELECTROCUTION!

Jacuzzi J-385 Specifications

General

Seating Capacity	6-7 Adults
Pumps	2
Circulation Pump	Yes
Primary Pump	2.5 HP
Secondary Pump	2.5 HP continuous duty, 4.8 HP breakdown torque
Electrical Requirements	240V
