Jacuzzi Whirlpool Bath EL21000B 10/06
ROUGHING-IN REFERENCE
NOTE: 1. THE OVERALL DIMENSIONS ARE NOMINAL WITH A TOLERANCE OF +0 AND -1/4" (6,4 mm).
2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow.
3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
4. Service Access dimensions given are minimum size.
46.61"
66"
32.97"
Ref.
69.68"
66"
37.23"
9.29"
40.94"
Fuzion™ 6666,
Right Hand
40.94"
32.97"
20" X 4"
Motor
12" H x 24" L
Service Access
Heater
Blower
60"
60"
77-3/4"
3"
7.5"
34-9/16"
59-1/2" Ref.
Heater
Motor
12" H x 24" L
Service Access
Opt. Service Access
Blower
12" x 4"*
46.61"
66"
32.97"
Ref.
69.68"
66"
37.23"
9.29"
40.94"
32.97"
20" X 4"
40.94"
Fuzion™ 6666 Undermount,
Right Hand
Motor
12" H x 24" L
Service Access
Heater
Blower
48"
65"
32"
Ref.
67-1/2"
65"
32"
Drain
CUTOUT
Fuzion™ 6666,
Right Hand units with Teak or Wenge
Corner Bath Cutout
Some tubs are supplied with cutout template and/or undermount template. Refer to CUTOUT on pages 6-8 for template part
numbers.
