Jacuzzi SALON User Manual

ENGLISH
11
Jacuzzi Whirlpool Bath EL21000B 10/06
ROUGHING-IN REFERENCE
NOTE: 1. THE OVERALL DIMENSIONS ARE NOMINAL WITH A TOLERANCE OF +0 AND -1/4" (6,4 mm).
2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow.
3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
4. Service Access dimensions given are minimum size.
11.04"
60"
42"
30"
3.84"
13" x 4"
2"
Motor
Heater
12" H x 24" L Service Access
Blower
Duetta™ 6042,
Right Hand
11.04"
66"
36"
33"
3.84"
13" x 4"
2"
Motor
Heater
12" H x 24" L Service Access
Blower
Duetta™ 6636,
Right Hand
11.04"
66"
42"
33"
3.84"
13" x 4"
2"
Motor
Heater
12" H x 24" L Service Access
Blower
Duetta™ 6642,
Right Hand
72"
42"
36"
11"
3-1/2"
14" x 4"
Motor
Heater
2"
12" H x 24" L
Service Access
Blower
Duetta™ 7242,
Right Hand
10-1/2"
36"
3"
42"
72"
12-1/8"
5-1/4"
29-7/8"
Motor
12" H x 24" L
Service Access
Heater
Blower
18" x 4"
Venicia™,
Right Hand
Some tubs are supplied with cutout template and/or undermount template. Refer to CUTOUT on pages 6-8 for template part
numbers.
NOTE: On oval tubs the motor and blower mounting plates extend beyond the bath rim.
