Jaga JRT-100TW - B. 0-10 V BMS WITH WATER- AND ROOM TEMPERATURE MONITORING (AUTO-CHANGE-OVER); B.1. FACTORY SETTINGS; B.1. FACTORY SETTINGS CONTINUED; B.1. FACTORY SETTINGS ADDITIONAL

44
JAGA NV | BRIZA   JFCC | MANUEL | .. | V..
B. 0  10V BMS WITH WATER AND ROOM TEMPERATURE MONITORING
AUTOCHANGEOVER
Configuration code : FCC.BRC / FCC.BRC / FCC.BRC
4⁰C
1⁰C
1⁰C
2⁰C
Standby mode
Only in combination with a suitable heat
pump and control valve for heating and
cooling
The device automatically enters cooling mode when the water temperature is 
°
C/°F below the room temperature. If
the differential between room and water temperature is less than 
°
C/°F, the device will automatically switch to standby.
The unit is in standby. The unit automatically starts a new cycle if the preset temperature is reached.
The device automatically enters heating mode when the water temperature is 
°
C/°F above the room temperature.
If the differential between room and water temperature is less than 
°
C/°F higher than the room temperature, the
device will automatically switch to standby.
strain relief strain relief
POWER 45W
INPUT: 110-240VAC
OUTPUT: 24V
NL
15120045
GND GND GND GNDNTC1 V.H. V.C.0-10V0-10V0-10V +24V
GND 0-10V 24V
GND 24V
GND 24V
+24V RC IN/OUT GND
Tsens 1
CONTROL PANEL
I2CRS485 A/B
CO2PC / RF
THERMOSTATE 1
DIPSWITCH
Tsens 2
Tsens 3
Tsens 4
JAGA
12345678
ON
(230V - 50Hz)
[C]
[B]
[D]
MODE
[F]
[I]
[A]
[G] [H]
4-pipe
4-pipe
POWER 45W
INPUT: 110-240VAC
OUTPUT: 24V
NL
15120045
GND GND GND GNDNTC1 V.H. V.C.0-10V0-10V0-10V +24V
GND 0-10V 24V
GND 24V
GND 24V
+24V RC IN/OUT GND
Tsens 1
CONTROL PANEL
I2CRS485 A/B
CO2PC / RF
THERMOSTATE 1
DIPSWITCH
Tsens 2
Tsens 3
Tsens 4
JAGA
12345678
ON
(230V - 50Hz)
[C]
[D]
MODE
[F]
[I]
[A]
[H]
2-pipe
