. Disable power charge .
. Press and hold down both the [-] and [+] button on the circuit board and switch on the
power again. The blue LED will light up, followed by the green LED  seconds later and
the red LED  seconds later. Release the buttons as soon as all  LEDs are flashing .
. The controller will return to the Factory Default settings, all LEDs will flash for  seconds .
.. CIRCUIT BOARD ERROR CODE
Error sensor [B]/[C] - Check the water temperature sensor
Error sensor [J] - Check the room temperature sensor
