Jain Technology XONIC 100L User Manual

Xonic 100L, 2021
12
Section 5. INSTALL
For proper installation, please read this section carefully. After input pipe and liquid data, user can
install quickly and easily.
Sensor Type User must have correct transducer for the pipe.
Xonic 100 has 5 types of transducers and Xonic 100 will automatically
recommend proper transducers for the site.
If the Xonic 100 recommends size D type, then user must have D type
transducers.
If the Xonic 100 recommends size D1 type, then user must have D1 type
transducers.
Choose the transducer according to the sensor type displayed in the list.
Sampling Clock Xonic 100 automatically select SAMPLING CLOCK, so user does not need
to change.
Mounting Type
Normally, CLAMP ON V is best for most applications. V method is more
accurate, and easy to install. V method means installation mode which
mount two transducers onto one pipe side as per below:
MAIN MENU
1 . GENERAL
2 . CH SELECT 1 . B TYPE
3 . PIPE INSTALL 2 . B1 TYPE
4 . LIQUID 1 . SENSOR TYPE 3 . C TYPE
5 . INSTALL 2 . SAMPLING CLK 4 . C1 TYPE
6 . OPERATE 3 . MOUNT TYPE 5 . D TYPE
7 . FLOW 4 . SENSOR DISTANCE 6 . D1 TYPE
8 . IN/OUTPUT 5 . INSTALL INFO. 7 . E TYPE
9 . DATALOG 6 . AUTO INSTALL 8 . E1 TYPE
0 . DIAG
7 .
ACTUAL ZERO 9 . F TYPE
SENSOR TYPE
INSTALL
1 . SENSOR TYPE
2 . SAMPLING CLK
3 . MOUNT TYPE 1 . SAMPLING 20ns
4 . SENSOR DISTANCE 2 . SAMPLING 40ns
5 . INSTALL INFO. 3 . SAMPLING 80ns
6 . AUTO INSTALL 4 . SAMPLING 160ns
7 .
ACTUAL ZERO 5 . SAMPLING 320ns
SAMPLING CLK
INSTALL
1 . SENSOR TYPE
2 . SAMPLING CLK
3 . MOUNT TYPE
4 . SENSOR DISTANCE
5 . INSTALL INFO.
6 . AUTO INSTALL 1 . CLAMP-ON V
7 .
ACTUAL ZERO 2 . CLAMP-ON Z
MOUNT TYPE
