Jain Technology XONIC 100L User Manual

Xonic 100L, 2021
4
Preview
Introduction Xonic 100L Clamp-On Ultrasonic Flowmeter is fully digitalized, the state-
of-art flowmeter that use DSP (digital signal processing) technology to
measure time difference of ultrasonic signals. Please read this manual
carefully before installation and operation to ensure the best performance.
Contents in this manual is subject to change by the manufacturer without
any prior notice to the user.
Safety Consideration Xonic 100L uses external power of AC110~220V . Follow all electrical and
electronic safety rules to prevent any safety accident or damage of the flow
computer during installation. Most applications are near to moisture, thus,
be careful of any electric shock.
Installation Steps Select best pipe installation point for transducer.
1. Input PIPE DATA.
2. Check the SENSOR DISTANCE displayed in flow computer.
3. Select the sensor INSTALLATION PLACE.
4. Mount the SENSOR horizontally to the pipe.
5. Install FLOW COMPUTER.
6. Connect the sensor and the flow computer via cable.
7. Supply POWER to the flow computer and turn the switch ON.
8. Input necessary DATA such as output and relay.
Specifications
Type
Clamp-On Ultrasonic Flowmeter
Principle
Transit-Time
Pipe Size
12 ~ 6000 mm
Accuracy
±1.0 % (single path), ±0.5 % (dual path)
Flow Velocity
±0.02 ~ 12.0 m/s
Turn-Down Ratio
500:1
Repeatability
0.25%
Required Straight
Run
Upstream 10D, Downstream 5D
(single path)
Upstream 5D, Downstream 3D
(dual path)
Data Input
Two 4~20mADC
Data OUTPUT
Two 4~20mADC for flow
Relay for Total
RS-232C / 485 Modbus
Data Logger
32 Mbytes (above 1.000,000 times)
Display
Graphic Color LCD
(Flow, Total, Velocity, Delta T,
Oscilloscope Shape)
Temperature
Flow Computer -20 ~ +75 ℃
Transducer -40 ~ +120 ℃
Power
110 ~ 220 VAC (12 ~ 24VDC option)
Enclosure
IP65
Transducer
IP68, submersible

Jain Technology XONIC 100L Specifications

General

Brand	Jain Technology
Model	XONIC 100L
Category	Measuring Instruments
Language	English
