Section 3. Input PIPE Data
Pipe Unit Select pipe unit: METRIC or US units (inch)
Pipe Material Select pipe material from list.
Pipe Sonic Vs N/A
Pipe Diameter Input pipe diameter using numeric keys.
Pipe Thickness Input pipe wall thickness using numeric keys.
MAIN MENU
1 . GENERAL
2 . CH SELECT
3 . PIPE 1 . PIPE UNIT
4 . LIQUID 2 . PIPE MATERIAL
5 . INSTALL 3 . PIPE SONIC Vs
6 . OPERATE 4 . PIPE DIAMETER
7 . FLOW 5 . PIPE THICKNESS
8 . IN/OUTPUT 6 . LINING MATERIAL PIPE UNIT
9 . DATALOG 7 . LINING SONIC Vs 1 . Metric(mm)
0 . DIAG 8 . LINING THICKNESS 2 . US units(inch)
PIPE
1 . CARBON STEEL
2 . DUCTILE_IRON
1 . PIPE UNIT 3 . CAST_IRON
2 . PIPE MATERIAL 4 . SUS
3 . PIPE SONIC Vs 5 . ALUMINUM
4 . PIPE DIAMETER 6 . COPPER
5 . PIPE THICKNESS 7 . BRASS
6 . LINING MATERIAL 8 . PVC
7 . LINING SONIC Vs 9 . FRP
8 . LINING THICKNESS 0 . POLYETHYLENE
PIPE
PIPE MATERIAL
1 . PIPE UNIT
2 . PIPE MATERIAL
3 . PIPE SONIC Vs
4 . PIPE DIAMETER
5 . PIPE THICKNESS
6 . LINING MATERIAL
7 . LINING SONIC Vs
8 . LINING THICKNESS _. _ _ _ _
UNIT : mm
PIPE DIAMETER
PIPE
1 . PIPE UNIT
2 . PIPE MATERIAL
3 . PIPE SONIC Vs
4 . PIPE DIAMETER
5 . PIPE THICKNESS
6 . LINING MATERIAL
7 . LINING SONIC Vs
8 . LINING THICKNESS _. _ _ _ _
PIPE THICKNESS
UNIT : mm
PIPE
