Specifications XT3 User Manual
Janam Technologies LLC Version 1, March 2020 Specifications 14—1
Janam XT3 Specifications
14
TECHNICAL
Operating System Android 9 (upgradeable)
Processor 2.2GHz Octa-core Qualcomm Snapdragon™ SDM660 processor, Adreno 512 GPU
Memory 3GB/32GB (WLAN) or 4GB/64GB (WWAN)
Expansion User-accessible microSD card slot with SD and SDXC support
Power 2900mAh rechargeable Li-ion battery (5800mAh optional)
PHYSICAL
Dimensions 6.1” L x 3.2” W x .8” D / 156mm L x 82mm W x 21mm D
Weight 9.5oz / 272g including battery
Display 5 inch High Definition (720x1280) WXGA with Corning Gorilla Glass 3;
exceptionally bright (500 nits), outdoor viewable; anti-raindrop
Touch Panel Capacitive multi-touch screen
ENVIRONMENTAL
Operating Temperature -4º to 140º F / -20º to 60º C
Storage Temperature -13º to 158º F / -25º to 70º C
Humidity Non-condensing, 95%
Drop Multiple 5ft / 1.5m drops to concrete on all sides across a wide
temperature range per MIL-STD 810G
Water & Dust IP67
Electro Static Discharge (ESD) +/- 15kV air; +/- 8kV contact
INTERFACE FEATURES
Audio 3.5mm headset jack; speaker; microphone
Alerts Vibration; LED indicators
Connectors USB 2.0
LED Indicators two dual-color LED indicators
External Buttons 4 hard keys (home; menu; back button; user-programmable)
DATA CAPTURE
Imager Honeywell N6703 1D/2D imager
RFID/NFC Reads NFC Forum Tag 1 to 5, ISO14443 Type A, ISO14443 Type B, ISO15693, MIFARE®
1k/4k/Plus/UltraLight/ DESFire, Sony FeliCa on the 13.56 MHz range
WIRELESS COMMUNICATION
WWAN EDGE/GPRS/GSM; WCDMA; LTE
WLAN Dual-band 802.11a/b/g/n/ac/d/h/i/k/r/v fast roaming
Security IEEE 802.11n; WEP / WPA / WPA2 / WEP, RC4 Algorithm; TKIP, RC4 Algorith; AES,
Rijndael Algorithm; PEAP/MS-CHAPv2, EAP-TLS; EAP- TTLS; PEAP-GTC; LEAP
WPAN Bluetooth v5 (BLE)
MOBILE APPURTENANCES
Motion Sensor Gyroscope; Accelerometer; Ambient light sensor; Proximity sensor; Digital compass
GNSS A-GPS with support for GPS, QZSS, GLONASS, Galileo and Beidou
Camera 13.0MP color rear-facing autofocus camera with user-controllable LED flash
and 5.0MP front-facing camera
ACCESSORIES Single-slot Ethernet cradle kit, four-slot charging cradle kit, trigger handle, vehicle
cradle, single-dlot USB/charging cradle kit, four-slot battery charging kit, handstrap,
UHF RFID sled
SAFETY/REGULATORY
Safety IEC 60950-1; EMC; RF; SAR; LED; Laser
Radio FCC; IC; ICEC; CE
Environment UL Listing (US and Canada) Class I Div 2, Groups A, B, C, D, RoHS, China RoHS
