Boot ROM inbuilt Menu, self tests, setups, etc 5 - 6
Revision 1 - 07 July
1999 Event 4 TECHNICAL MANUAL
Misc
Use this option to run miscellaneous tests on the console. When selected the following
options are displayed:
1. DMX In
2. Vers
3. Trash RAM
DMX In
DMX signal from an external source is connected to the MIDI input using the adaptor
cable detailed in Appendix D. The DMX signal present is displayed on the VDU. Note
that both DMX outputs transmit a test data pattern that can be used to feed into the
input, however only one should be plugged into the MIDI input. Note also that the data
pattern changes each time the test is run.
Press Exit to terminate the test.
Vers
The software version of the test routines is output to L4 and L5 in flashes. The green
LED (L5) flashes once at the start of the test. The version is then displayed in red LED
(L4) flashes. The version is also displayed on the master LCD at startup, and for this
reason this test is mainly for use when no Master card is available.
Trash RAM
The system memory is completely cleared.
Boot
The console is restarted. This is generally used when use of the self tests has been
completed and it is desired to start the main operating software. Holding the Enter
button down immediately after activating this option allows re-entry to the self tests
and setups.
