Jands Event 4 Technical Manual

Technical Data and Specifications 8-1
Revision 1 - 07 July
1999 Event 4 TECHNICAL MANUAL
8. Technical Data and Specifications
Event 4 Specifications
Mains Supply: 90-265VAC, 47-63Hz, 60 watts max.
Mains Fuse: 2A, M205 delay type
Temperature: 40°C maximum ambient
Outputs: DMX Out 1 & 2, MIDI Thru, MIDI Out, Two Desk Lamps, VGA
Inputs: Keyboard (AT type), MIDI In
Control channels: 36 preset fader – 360, 24 preset fader - 240
Data Protocol: USITT DMX-512/1990, electrically conforms to RS485A.
Memory capacity: 2Mbytes
Disk Drive: IBM format DOS 3.0 and above, 1.44MB high density
Desk Lamps: 12 volt 5 watt x 2, maximum output 10W total
Construction: All steel chassis with lexan/polycarbonate covered control surface
Dimensions: L: 945mm W: 530mm H: 110mm
Weight: 19 kg net / 24.5 kg shipping
Ingress protection: IP20
