Jands Event 4 Technical Manual

Circuit Diagrams and Overlays D - 1
Revision 1 - 07 July
1999 Event 4 TECHNICAL MANUAL
R9
270R
IC2
75176
OPTO1
H11N1
8
5
7
6
2
1
5
4
6
IC1
75176
8
5
9
10
11
8
IC3C
74HC10
3
4
5
6
IC3B
74HC10
1
2
13
12
IC3A
74HC10
VCC
VCC
VCC
D1
1N914
R1
220R
VCC
VCC
VCC
R2
10K
R3
10K
R4
10K
R5
10K
VCC
1
2
3
From DMX1 output
1
2
3
From DMX2 output
4
5
From MIDI output
R6
220R
R7
220R
VCC
5
4
To MIDI Input
VCC
5
4
From Keyboard Input
C1
100nF
Appendix D: DMX to MIDI adaptor
A DMX to MIDI adaptor cable is required to run some of the Auxiliary tests contained in the Boot
ROM. The adaptor should be wired as shown:
DMX pin MIDI pin Detail
3 5 connect with 220R 0.25W 5% resistor
2 4 direct connection
1 2 direct connection
Appendix E: 2 x DMX, MIDI signal combiner
A DMX /MIDI combiner circuit is required to run some of the Auxiliary tests contained in the
Boot ROM.
