Page 24
ePump
™
Series Pumps, Installation and Operation Manual
Section 7. Product Specifications and Technical Data
Key No. Description Model No. Part No.
1 Motor, ePump Series Replacement Kit JEP2.0 R0474403
1 Motor, ePump Series Replacement Kit JEP1.5 R0474402
2 Backplate, Pump, SHP, PHP/MHP Replacement Kit All R0445200
3
Impeller, Assembly, SHP, PHP, JEP JEP2.0 R0445305
3
Impeller, Assembly, SHP, PHP, JEP JEP1.5 R0445304
4 Diffuser with O-ring and Hardware All R0445400
5
Mechanical Seals (Carbon and Ceramic) All R0479400
6 Body, Pump All R0445601
7 Motor Mounting Foot Assembly, SHP All R0445700
8 Locking Ring (With Lid and O-ring) All R0445800
9 Filter Basket All R0445900
10 Plug, Drain (Set of 2) All R0446000
11 Tail Piece (2" by 2½") with Union Nut and O-ring (Set of 2) JEP2.0, JEP1.5 R0446101
12 Seal, Lid All R0446200
13 Blue Pressure Test O-ring All R0479000
14 O-ring, Backplate All R0446300
15 O-ring, Tail Piece (Set of 2) All R0446400
16 Diffuser/Impeller Hardware Set All R0446500
17 Backplate Hardware with Set of 8 Bolts and Washers All R0446600
18 Motor Hardware with Set of 4 Bolts and Washers All R0446700
19 Screws, Motor Mounting Foot (Set of 2) All R0446800
20 Speed Drive
(w/Cover & Hardware), ePump, Replacement Kit All R0474900
21 Cover Speed Drive (w/ Hardware), ePump All R0475000
22 Cover Fan, 1-3 HP, ePump Replacement Kit All R0474800
23 Hardware Speed Drive, ePump All R0475100
24 Connector, Speed Drive, ePump (4-Pin Connector) All R0660900
7.1 Replacement Parts List and Exploded View
To order or purchase parts for Jandy pumps, contact your nearest Jandy dealer. You can also contact the Jandy
Customer Service Department at 800.822.7933, or send an e-mail message to info@jandy.com.
