Jandy ePump Series User Manual

Page 27
ePump
™
Series Pumps, Installation and Operation Manual
7.3 Physical and Operational Specifications
7.3.1 Specifications
Model No. HP Voltage Watts Pipe Size Carton Weight Overall Length 'A'
JEP2.0 0.25 - 2.7 230 VAC 2,250 W 2½ - 3" 50 lbs. 34¼"
JEP1.5 0.25 - 2.2 230 VAC 2,100 W 2½ - 3" 50 lbs. 34¼"
16 1/8"
14 3/4"
34¼
15 1/4"
Front Edge of Union to
Center of Bolt Holes
Bolt Holes,
Center to Center
9"
11 3/8"
10 3/8"
NOTE When installing a pump, leave a minimum of two feet (2 ft) of clearance above the pump for removal of
the strainer basket.
7.3.2 Dimensions
7.4 Replacement Motor Guide
Pump Model A.O. Smith/Century
JEP2.0 M48A40D58
JEP1.5 M48D42D58

Jandy ePump Series Specifications

General

Variable Speed	Yes
Voltage	230V
Energy Efficiency	ENERGY STAR Certified
Control	Digital
Motor Type	Permanent Magnet
Speed Settings	Programmable
Warranty	3 years
