Jandy JE1500T - Figure 8. JE Single-Phase Electrical Supply Wiring Diagram

Page 13
ENGLISH
Jandy
®
Pro Series JE Heat Pumps
|
Installation and Operation Manual
 
COMPRESSOR CAPACITOR
FAN CAPACITOR
24 VAC
TRANSFORMER
POWER
INTERFACE
W
BK
WATER PRESSURE
SWITCH
CONTACTOR
FAN RELAY
COMPRESSOR
BK
R
BL
R
BK
BL
BK
BK
BR
W
BL
Y
Y
BL
W
BR
HIGH REFRIGERANT PRESS SWITCH
LOW REFRIGERANT PRESS SWITCH
WATER
TEMP
DEFROST
TEMP
BK
R
R
L1 L2
Y
Y
Y
Y
BK
W
R
R
FAN MOTOR
BR BR/W
BK
W
W
W
W
W
R
R
GROUND
GR
GR
R
REVERSING VALVE
(OPTIONAL)
BL
HARD START CAPACITOR (OPTIONAL)
BK
BK BK
BK
FACTORY INSTALLED 208/230 VAC FIELD INSTALLED 208/230 VAC
FACTORY 24 VAC HARNESS
FACTORY OPTIONAL 24 VAC FACTORY OPTIONAL 208/230 VAC
JE SERIES
230 VAC
SINGLE PHASE
60 Hz
WIRING DIAGRAM
JE 3000TR & JE3000TR3 ONLY
