Page 5
ENGLISH
Jandy
®
Pro Series JE Heat Pumps
|
Installation and Operation Manual
not needed at the heat pump; connections are made
inside of the heat pump electrical compartment.
Conduit may be attached directly to the heat pump
jacket.
Flex conduit is recommended for connecting
the electrical supply wires to the heat pump so
that the front panel may be removed easily for
servicing.
4. Electric cutout switch that will interrupt all power
to the unit. This switch must be within line of sight
of the heat pump.
5. Watertight conduit to run the electrical supply line.
Zodiac recommends installing
isolation valves on the inlet and outlet water
connections for ease of serviceability.
Suitable for indoor and outdoor use. Clearances shown
in Table 2 must be adhered to.
Plastic 2” PVC (Unions included)
Maximum
Optimum
Minimum
70 gpm (265 lpm)
60 gpm (230 lpm)
20 gpm (76 lpm)
75 psi
Voltage Requirements
1-Phase
3-Phase
230 VAC 60Hz
230 VAC 60Hz
(Model dependent)
600 PSI
See Figure 1 for heat pump’s dimensions and for
dimensions to critical connections.
See Table 1 for the Jandy Pro Series JE heat pump
technical specifications.
Install the Zodiac
®
heat pumps in accordance with the
procedures in this manual, local codes and ordinances,
and in accordance with the latest edition of the
appropriate national code. (See Section 1.4, “Codes and
Standards”.) Correct installation is required to assure
safe operation. The requirements for Zodiac heat pumps
include the following:
1. Field assembly (if required).
2. Appropriate site location and clearances.
3. Sufcient air ventilation.
4. Proper electrical wiring.
5. Adequate water ow.
This manual provides the information needed to
meet these requirements. Review all application and
installation procedures completely before continuing the
installation.
Indoor installations require special
considerations for condensate drainage and
venting the cold air produced by the heat
pump. Contact the Zodiac technical support
department at (800) 822-7933.
When pool equipment is located below the pool
surface, a leak from any component can cause
large scale water loss or ooding. Zodiac cannot
be responsible for such water loss or ooding or
resulting damage.
Avoid placing the heat pump in locations where it can
cause damage by water or condensate leakage. If this is
not possible, provide a suitable drain pan to catch and
divert any leakage.
All criteria given in the following sections reflect
minimum clearances. However, each installation must
also be evaluated, taking into account the prevailing
local conditions such as proximity and height of walls,
and proximity to public access areas.
The heat pump must be placed to provide clearances on
all sides for maintenance and inspection. See Table 2.
Access in front of the heat pump of 24” (60 cm)
provides adequate room for serviceability.
If the heat pump is to be installed in a garage or under
a vertical overhang, the unit must have a minimum of
5 feet
(1.5 meters)
clearance from the top of the heat
pump.
In the U.S., the heat pump must be installed at least 5 feet
(1.5 meters) from the inside wall of the pool or spa unless the
