ENGLISH
Jandy
®
Pro Series JE Heat Pumps
|
Installation and Operation Manual

         VOLTAGE
230V/60HZ 230V/60HZ 230V/60HZ 208/230V/60HZ/3 230V/60HZ 208/230V/60HZ/3
OUTPUT*
72,000 BTUs 108,000 BTUs 119,000 BTUs 137,000 BTUs
INPUT*
3.83 kW 5.03 kW 5.34 kW 6.37 kW
COP*
5.5 6 6.2 6.3
OUTPUT, STANDARD RATING CONDITIONS**
67,000 BTUs 92,000 BTUs 106,000 BTUs 127,000 BTUs
COP, STANDARD RATING CONDITIONS**
5.2 5.7 5.6 6.0 5.9 6.0 5.9
OUTPUT, LOW AMBIENT**
46,000 BTUs 64,000 BTUs 74,000 BTUs 86,000 BTUs 86,000 BTUs
COP, LOW AMBIENT**
4.0 4.0 4.0 4.2 4.0 4.2 4.0
RLA (RUNNING LOAD AMPS)
19.87A 30.77A 32.05A 23.21A 32.05A 25.00A
LRA (LOCKED ROTOR AMPS)
105A 178A 148A 164A 185A 164A
MINIMUM CIRCUIT AMPACITY
26.14A 40.21A 41.81A 30.76A 41.81A 33.0A
MAX OVER CURRENT PROTECTION***
45A 60A 60A 45A 60A 50A
HEAT EXCHANGER
Titanium
COMPRESSOR
Reciprocating Scroll Scroll Scroll
CABINET
ABS
REFRIGERANT
64 Oz, R410A 78 Oz, R410A 78 Oz, R410A 78 Oz, R410A 118 Oz, R410A 126 Oz, R410A 118 Oz, R410A 126 Oz, R410A
REFRIGERANT HIGH PRESSURE ALARM
600 PSI (reset to 460 PSI)
REFRIGERANT LOW PRESSURE ALARM - HEATING UNITS
58 PSI (reset to 127 PSI)
REFRIGERANT LOW PRESSURE ALARM - REVERSE UNITS
35 PSI (reset to 74 PSI)
LOW WATER FLOW ALARM
20 GPM
MAXIMUM HEIGHT BELOW WATER LEVEL
10 feet below pool level
MINIMUM HEIGHT ABOVE WATER LEVEL
5 feet above pool level
OPTIMAL WATER FLOW
30 GPM 42 GPM 48 GPM 48 GPM 57 GPM 57 GPM
MINIMUM WATER FLOW
20 GPM
MAXIMUM WATER FLOW
70 GPM
AIR FLOW
2100 CFM 3600 CFM
WATER TEMPERATURE DIFFERENTIAL (DELTA T)
Adjustable between 1°F to 5°F
UNION SIZE
2”
WEIGHT
175 lbs 220 lbs 223 lbs 223 lbs 228 lbs 230 lbs 228 lbs 230 lbs
* Test Conditions: 80˚ F Air, 80% RH, 80˚ F Water, Outside the scope of AHRI Standard 1160 (I-P) ** Rated in accordance with AHRI Standard 1160 (I-P) *** Max Over Current Protection refers to the maximum breaker size allowed. If this value is not a standard breaker size, use the next smallest standard size breaker. The breaker size must not be smaller than the Minimum Circuit Ampacity value.
